D-Link DGE-528T Copper Gigabit PCI Network Card – 10/100/1000Mbps, Full-Duplex, Low-Profile Bracket

700EGP

The D-Link DGE-528T is a high-performance 10/100/1000Mbps copper Gigabit PCI card for desktop PC. Installable in a PC equipped with PCI expansion slots, this card turns a desktop computer into a high-bandwidth Gigabit workstation or a server running at 2000Mbps full-duplex speed.

4 in stock

SKU: 2143456 Category:
Description

Description

The D-Link DGE-528T Copper Gigabit PCI Card is the perfect upgrade for aging desktops needing faster network performance. Designed for legacy systems, this PCI card delivers 1Gbps speeds over standard copper Ethernet (RJ45), enabling seamless 4K streaming, large file transfers, and online gaming.

Featuring auto-negotiation, the DGE-528T automatically adjusts between 10/100/1000Mbps to match your network’s capabilities. The included low-profile bracket ensures compatibility with slim PC cases, while full-duplex mode maximizes bandwidth efficiency for uninterrupted uploads and downloads.

Easy to install, this card supports plug-and-play functionality on Windows 10/11, Linux, and other major operating systems. Its energy-efficient design reduces power consumption, making it ideal for always-on systems.

SPECS
Standards • IEEE 802.3, 802.3u, 802.3ab
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control
• PCI local bus 2.3
• Universal Bus Support 3.3 V / 5 V
Topology • Star
Data Transfer Rate • Gigabit Ethernet:
• Up to 2000 Mbps full duplex
• Fast Ethernet
• 100 Mbps half duplex
• 200 Mbps full duplex
• Ethernet:
• 10 Mbps half duplex
• 20 Mbps full duplex
Interface • PCI • Half-height card suitable for low-profile cases
Supported Functions • 7 KB Jumbo Frames
• IEEE 802.1p Priority Queues
• IEEE 802.1Q VLAN Tagging
• Wake on LAN
• Diagnostics Utility
Functionality
OS Support • Microsoft Windows XP/Vista/7/8/8.1/10
• Microsoft Windows Server 2000/2003/2008/2012
• Linux for Kernel 2.4/2.6/3.16
• Free BSD
• NDIS 2 for DOS
• Novell client for DOS
• Novell client for server 5.x/6.x
• Mac OS X 10.2/10.3/10.4
Diagnostic LEDs • 10/100/1000 Link • 10/100/1000 Activity
Physical
Dimensions • 121 x 114.7 x 19 mm (4.76 x 4.52 x 0.75 inches)
Weight • 46.6 grams (1.64 ounces)
Power Consumption • 2.236 W maximum
Temperature • Operating: 0 to 40 °C (32 to 104 °F) • Storage: -25 to 55 °C (-13 to 131 °F)
Humidity • Operating: 5% to 90% non-condensing • Storage: 5% to 90% non-condensing
Certifications • CE • FCC
Order Information
Part Number Description
DGE-528T PCI Gigabit Ethernet Adapter
