CPU Intel Core i5-12400F Processor

Description

Essentials

Product Collection:     12th Generation Intel® Core™ i5 Processors

Code Name:     Products formerly Alder Lake

Vertical Segment:     Desktop

Processor Number:     i5-12400F

Status:     Launched

Launch Date:     Q1’22

Lithography:     Intel 7

Use Conditions:     PC/Client/Tablet

CPU Specifications

Total Cores:     6

# of Performance-cores:     6

# of Efficient-cores:     0

Total Threads:     12

Max Turbo Frequency:     4.40 GHz

Performance-core Max Turbo Frequency:     4.40 GHz

Performance-core Base Frequency:     2.50 GHz

Cache:     18 MB Intel® Smart Cache

Total L2 Cache:     7.5 MB

Processor Base Power:     65 W

Maximum Turbo Power:     117 W

Memory Specifications

Max Memory Size (dependent on memory type) :     128 GB

Memory Types:     Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s

Max # of Memory Channels:     2

Max Memory Bandwidth:     76.8 GB/s

Expansion Options

Direct Media Interface (DMI) Revision:     4.0

Max # of DMI Lanes:     8

Scalability:     1S Only

PCI Express Revision:     5.0 and 4.0

PCI Express Configurations:      ‡Up to 1×16+4, 2×8+4

Max # of PCI Express Lanes:     20

Package Specifications

Sockets Supported:     FCLGA1700

Max CPU Configuration:     1

Thermal Solution Specification:     PCG 2020C

TJUNCTION:     100°C

Package Size:     45.0 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator:     3.0

Intel® Thread Director:     No

Intel® Deep Learning Boost (Intel® DL Boost) :     Yes

Intel® Optane™ Memory Supported :     ‡Yes

Intel® Speed Shift Technology:     Yes

Intel® Turbo Boost Max Technology 3.0:      ‡No

Intel® Turbo Boost Technology :     ‡2.0

Intel® Hyper-Threading Technology :     ‡Yes

Intel® Virtualization Technology (VT-x) ‡:     Yes

Intel® Virtualization Technology for Directed I/O (VT-d) :     ‡Yes

Intel® VT-x with Extended Page Tables (EPT) :     ‡Yes

Intel® 64 ‡:     Yes

Instruction Set:     64-bit

Instruction Set Extensions:     Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States:     Yes

Enhanced Intel SpeedStep® Technology:     Yes

Thermal Monitoring Technologies:     Yes

Intel® Volume Management Device (VMD) :     Yes

Security & Reliability

Intel® Standard Manageability (ISM) ‡:     Yes

Intel® AES New Instructions:     Yes

Secure Key:     Yes

Intel® OS Guard:     Yes

Execute Disable Bit ‡:     Yes

Intel® Boot Guard:     Yes

Mode-based Execute Control (MBEC) :     Yes

Intel® Control-Flow Enforcement Technology:     Yes
