XPG PROBE 700W 80 PLUS Bronze Power Supply

The XPG PROBE 700W is an ATX power supply designed to deliver stable and reliable power for gaming PCs, desktop computers, and performance-oriented systems. It provides 700W of total power and carries an 80 PLUS Bronze efficiency certification.

Built to the ATX 2.52 standard, the PROBE 700W can reach up to 87% efficiency at 50% load, helping reduce wasted energy while maintaining reliable power delivery to system components.

The power supply features a strong +12V rail rated at 54A and 648W, providing the majority of its total output capacity for power-hungry components such as the CPU and graphics card.

Cooling is handled by a 120mm sleeve-bearing fan with an intelligent fan curve designed to provide effective cooling while keeping operating noise under control.

The XPG PROBE 700W includes multiple protection mechanisms, including Over Voltage Protection, Over Power Protection, Short Circuit Protection, Under Voltage Protection, Over Temperature Protection, and Surge & Inrush Protection.

With a compact 140mm depth, the PROBE 700W is designed to fit easily into a wide range of ATX-compatible PC cases. It also includes two EPS 8-pin (4+4) connectors for CPU power and a standard 24-pin ATX motherboard connector.

Key Features

• 700W continuous power output
• 80 PLUS Bronze certification
• Up to 87% efficiency at 50% load
• ATX 2.52 compliant
• +12V rail rated at 54A / 648W
• 120mm sleeve-bearing fan
• Intelligent fan curve
• Multiple electrical protection systems
• 140mm compact PSU depth
• Two EPS 8-pin (4+4) CPU power connectors
• 100–240V input voltage
• MTBF of more than 100,000 hours at 25°C
